DH-XVR1B08H-I 8 Channel Penta-brid 5M-N/1080p Cooper 1U 1HDD WizSense Digital Video Recorder

Technical Specification
System
Main Processor Embedded processor
Operating System Embedded linux
SMD Plus
Performance 8 channels
AI Search Search by target classification (Human, Vehicle)
Video and Audio
Analog Camera Input 8 channels, BNC
HDCVI Camera Input 5MP, 4MP, 1080p@ 25/30 fps, 720p@ 50/60 fps, 720p@
25/30 fps
AHD Camera Input 5MP, 4MP, 1080p@ 25/30 fps, 720p@ 25/30 fps
TVI Camera Input 5MP, 4MP, 1080p@25/30 fps, 720p@25/30 fps
CVBS Camera Input PAL/NTSC
IP Camera Input 8+4 channels, each channel up to 6MP
Audio In/Out 1/1, RCA
Two-way Talk Reuse audio in/out, RCA
Recording
Compression AI Coding/H.265+/H.265/H.264+/H.264
Resolution 5M-N; 4M-N; 1080p; 1080N; 720p; 960H; D1; CIF
Record Rate
Main stream: All channel 5M-N (1 fps–10 fps);
4M-N/1080p (1 fps–15 fps); 1080N/720p/960H/
D1/CIF (1 fps–25/30 fps)
Sub stream: D1/CIF (1 fps–15 fps)
Bit Rate 32 kbps–6144 kbps per channel
Record Mode
Manual; Schedule (General, Continuous); MD (Video
detection: Motion Detection, Video Loss, Tampering);
Alarm; Stop
Record Interval 1 min– 60 min (default: 60 min), Pre-record: 1 s–30 s,
Post-record: 10 s–300 s
Audio Compression G.711A; G.711U; PCM
Audio Sample Rate 8 KHz, 16 bit per channel
Audio Bit Rate 64 kbps per channel
Display
Interface 1 HDMI; 1 VGA
Resolution 1920 × 1080, 1280 × 1024, 1280 × 720
Multi-screen Display When IP extension mode not enabled: 1/4/8/9
When IP extension mode enabled: 1/4/8/9/16
OSD Camera title; Time; Video loss; Camera lock; Motion
detection; Recording
Network
Interface 1 RJ-45 Port (100 MB)
Network Function
HTTP; HTTPS; TCP/IP; IPv4/IPv6; Wi-Fi; 3G/4G; SNMP;
UPnP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter;
PPPoE; DDNS; FTP; Alarm Server; P2P; IP Search
(Supports Dahua IP camera, DVR, NVS, etc.)
Max. User Access 128 users
Smart Phone iPhone; iPad; Android

Interoperability ONVIF 16.12, CGI Conformant
Video Detection and Alarm
Trigger Events Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot,
Buzzer and Screen Tips
Video Detection Motion Detection, MD Zones: 396 (22 × 18), Video Loss,
Tampering and Diagnosis
Alarm input N/A
Relay Output N/A
Playback and Backup
Playback 1/4/9
Search Mode Time/Date; Alarm; MD and Exact Search (accurate to
second)
Playback Function
Play; Pause; Stop; Rewind; Fast play; Slow Play; Next
File; Previous File; Next Camera; Previous Camera; Full
Screen; Repeat; Shuffle; Backup Selection; Digital Zoom
Backup Mode USB Device/Network
Storage
Internal HDD 1 SATA port, up to 6 TB capacity
eSATA N/A
Auxiliary Interface
USB 2 USB ports (USB 2.0)
RS485 N/A
RS232 N/A
Electrical
Power Supply DC 12V/2A
Power Consumption
(Without HDD) < 7W
Construction
Dimensions Cooper 1U, 198.3 mm × 203.4 mm × 41.5 mm
(7.81” × 8.01” × 1.63”)
Net Weight
(without HDD) 0.57 kg (1.26 lb)
Gross Weight 1.05 kg (2.31 lb)
Installation Desktop installation
Environmental
Operating Conditions -10°C to +45°C (+14°F to +113°F), 0%–90% (RH)
Storage Conditions -20°C to +70°C (-4°F to +158°F) , 0%–90% (RH)
Third-party Support
Third-party Support
Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP
Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung,
Sanyo, Sony, Videotec, Vivotek, and more
