- Door Station/System Parameters
- Operation System Embedded Linux operation system
- Flash 32 MB
- RAM 128 MB
- Door Station / Video Parameters
- Camera 2MP HD camera
- Night Vision Low illumination IR supplement mode:3 m
- Backlight Compensation Support
- Digital Noise Reduction Support
- WDR True WDR
- Field Of View Horizontal: 129° Vertical: 75°
- Video Compression Standard H.264
- Stream Main stream: 1080p@30fps, 720p@25fps Sub stream: D1@25fps
- Motion Detection Support
- Flash-Avoid Frequency50 Hz, 60 Hz
- Door Station/Audio Parameters
- Audio Input Built-in omnidirectional microphone
- Audio Output Built-in loudspeaker
- Audio Quality Noise suppression and echo cancellation
- Audio Compression StandardG.711 U
- Audio Compression Rate64 Kbps
- Audio Intercom Two-way audio communication
- Door Station/Network Parameters
- Network Protocol TCP/IP, RSTP
- Wired Network10/100 Mbps Ethernet
- Door Station/Device Interfaces
- RS-485 1
- Alarm Input 4
- Debugging Port 1
- Grounding 1
- TAMPER Switch 1
- Door Station/General
- Power Consumption＜ 10 W
- Working Temperature -40° C to 53° C(-40° F to 127.4° F)
- Working Humidity 10% to 95%
- Dimension 138 mm × 65 mm × 27 mm
- Installation Surface mounting
- Protection Level IP65
- Indicator 2
- Power Supply IEEE802.3af, standard PoE 12 VDC
- Indoor Station/System Parameters
- Operation System Embedded Linux operation system
- Memory 128 MB
- Flash 32 MB
- Indoor Station/Display Parameters
- Display Screen 7-inch colorful TFT screen
- Display Resolution 1024 × 600
- Operation Method Capacitive touch screen
- Indoor Station/Audio Parameters
- Audio Input Built-in omnidirectional microphone
- Audio Output Built-in loudspeaker
- Audio Quality Noise suppression and echo cancellation
- Audio Compression Standard G.711 U
- Audio Compression Rate 64 Kbps
- Indoor Station / Network Parameters
- Wired Network 10/100 Mbps self-adaptive
- Wireless Network Wi-Fi 802.11 b/g/n
- Protocol TCP/IP, SIP, RTSP
- RS-4851 RJ-45 10/100 Mbps self-adaptive
- Indoor Station / Device Interfaces
- RS-4851
- Alarm Input 8-ch alarm inputs
- Relay Output 2
- TF Card Max to 32 G, SD 2.0 or lower version
- Indoor Station/General
- Power Consumption ≤ 6 W
- Working Temperature‘ -10 °C to 55 °C (14 °F to 131 °F)
- Working Humidity 10% to 90%
- Dimension (L X W X H) 200 mm × 140 mm × 15.1 mm (7.9″ × 5.5 × 0.6\”)”
